4.9 ODD Module (Slot-load) 4 Replacement Procedures
Satellite A660/A665/A660D Maintenance Manual 4-29
4.9 ODD Module (Slot-load)
CAUTION: Handle the ODD module carefully. It can become hot during operation.
Removing the ODD Module (Slot-load)
Remove the ODD (optical disc drive) module according to the following procedures.
NOTE: Do not disassemble the ODD drive when it is working normally. Disassemble or
replace the ODD drive only if it fails.
1. Remove the logic upper assembly from the system.
2. Lift and remove the ODD frame (straight up) from the logic lower assembly.
3. Push the ODD outward (into the empty space left by the ODD frame) to release it from
the connector on the motherboard.
4. Lift and remove the ODD (straight up) from the logic lower assembly.
5. Carefully push the ODD button (eject button) outward and away from the logic lower
assembly, then remove.
Installing the ODD Module (Slot-load)
Install the ODD module according to the following procedures.
1. Replace the motherboard.
2. Place the ODD into the logic lower assembly (straight down) and slid it inward to connect
with the motherboard.
3. Place the ODD frame into the space between the ODD and the right edge of the logic
lower assembly.
4. Align the ODD knob (eject button) with (the outside of) the logic lower assembly and
carefully push it inward to secure it in place the ODD into the ODD bay.
5. Slide the ODD inward until it meets the end.
