4 Replacement Procedures 4.19 CPU
Satellite A660/A665/A660D Maintenance Manual 4-48
Installing the CPU
Install the CPU according to the following procedures.
1. Check to ensure the cam is in the unlock position.
2. Seat the CPU on the socket, using care not to damage the pins. Align the CPU with the
CPU socket using the triangle marker as a guide.
3. Rotate the cam clockwise to the lock position with a flat blade screwdriver.
