4.22 LCD Bezel 4 Replacement Procedures
Satellite A660/A665/A660D Maintenance Manual 4-51
4.22 LCD Bezel
Removing the LCD Bezel
Remove the LCD bezel according to the following procedures and Figures 4.40 and 4.41.
1. Remove the four rubber seals from the LCD bezel and four M2.5x5 screws securing the
LCD bezel to the display assembly as shown in Figure 4.40.
Figure 4.40 Removing four screws securing the LCD bezel to the display assembly
M2.5x5*2
M2.5x5*2
