Toshiba Satellite A660 Series Maintenance Manual

4 Replacement Procedures 4.8 Logic Upper Assembly
Satellite A660/A665/A660D Maintenance Manual 4-26
4.8 Logic Upper Assembly
Removing the Logic Upper Assembly
Remove the logic upper assembly according to the following procedures and Figures 4.17, 4.18
and 4.19.
1. Close the laptop and turn it over. Remove the thirteen M2.5x8 screws securing the logic
upper assembly as shown in Figure 4.17.
Figure 4.17 Removing thirteen screws from the bottom of the laptop
2. Turn the laptop over and open it. Remove the two M2.5x8 screws securing the logic
upper assembly as shown in Figure 4.18.
M2.5x8*13

Toshiba Satellite A660 Series Specifications

General

Optical Drive	DVD SuperMulti Drive
Wireless	Wi-Fi 802.11b/g/n
HDMI	Yes
Battery	6-cell Lithium-ion
Processor	Intel Core i5
RAM	4GB or 8GB DDR3
Storage	Up to 640GB HDD
Graphics	NVIDIA GeForce GT 330M
Operating System	Windows 7 Home Premium or Professional
Webcam	Yes, with built-in microphone
Audio	Stereo speakers, Dolby Advanced Audio
LAN	10/100 Ethernet
Card Reader	Multi-Card Reader
USB Ports	3 x USB 2.0
Ports	Microphone input, Headphone output
