Toshiba Satellite A660 Series Maintenance Manual

4 Replacement Procedures 4.6 TV Tuner Card and WLAN Card
Satellite A660/A665/A660D Maintenance Manual 4-22
Figure 4.13 Removing the TV tuner card
Installing the WLAN Card
Install the WLAN card according to the following procedures.
1. Insert the WLAN card into the connector as shown in Figure 4.12.
2. Press the WLAN card down and secure it with one M2.5x5 screw.
Connect the black WLAN antenna (auxiliary) to the connector on the left of the WLAN card, and
the white WLAN antenna (main) to the connector on the right.
Installing the TV Tuner Card
Install the TV tuner card according to the following procedures.
1. Insert the TV tuner card into the connector as shown in Figure 4.13.
2. Press the TV tuner card down and secure it with one M2.5x5 screw.
3. Attach the antenna to the TV tuner card.
M2.5x5*1

Toshiba Satellite A660 Series Specifications

General

Optical Drive	DVD SuperMulti Drive
Wireless	Wi-Fi 802.11b/g/n
HDMI	Yes
Battery	6-cell Lithium-ion
Processor	Intel Core i5
RAM	4GB or 8GB DDR3
Storage	Up to 640GB HDD
Graphics	NVIDIA GeForce GT 330M
Operating System	Windows 7 Home Premium or Professional
Webcam	Yes, with built-in microphone
Audio	Stereo speakers, Dolby Advanced Audio
LAN	10/100 Ethernet
Card Reader	Multi-Card Reader
USB Ports	3 x USB 2.0
Ports	Microphone input, Headphone output
