4 Replacement Procedures 4.4 Memory
Satellite A660/A665/A660D Maintenance Manual 4-16
4. Spread out the two memory lock latches so that the upper memory module pops up.
Please follow the procedure as shown in Figure 4.8.
Figure 4.8 Removing the RAM from the connectors
5. Pull the upper memory module up and out at an angle, using care to avoid touching the
connectors.
6. Repeat steps 4 and 5 to remove the lower memory module.
Installing the Optional Memory
Install the optional memory according to the following procedures after checking that the laptop
is turned off.
CAUTION: Install the optional memory after turning off the laptop. If this is violated, the
laptop or memory can be damaged.
7. Insert the lower memory module into the connector at an angle of 45 degrees.
8. Press down on the memory module so that it is secured with both memory lock latches.
9. Repeat steps 1 and 2 to install the upper memory module.
10. Reinstall the optional RAM door.
11. Secure the RAM door with one M2.5x5.6 screw.
