4 Replacement Procedures 4.9 ODD Module (Slot-load)
Satellite A660/A665/A660D Maintenance Manual 4-30
Disassembling the ODD (Slot-load)
NOTE: Do not disassemble the ODD when it is working normally. Disassemble or replace
the ODD only if it fails.
Disassemble the ODD according to the following procedures and Figure 4.20.
1. Remove the two M2x3 screws securing the ODD bracket.
2. Remove the ODD bracket from the ODD.
Figure 4.20 Disassembling the Slot-load ODD
Assembling the ODD (Slot-load)
Assemble the ODD according to the following procedures and Figure 4.20.
1. Seat the ODD bracket in the correct position and secure it with two M2x3 screws.
M2x3*2
