4 Replacement Procedures 4.3 HDD
Satellite A660/A665/A660D Maintenance Manual 4-12
2. Use your fingers to push the HDD in the direction indicated by the arrows in Figure 4.3.
Figure 4.3 Releasing the HDD from the connector
3. Pull the tab and remove the HDD as shown in Figure 4.4.
Figure 4.4 Removing the HDD from the HDD bay
NOTE: Do not disassemble the HDD pack when it is working normally. Disassemble or
replace the HDD pack only if it fails.
