Toshiba Satellite A660 Series Maintenance Manual

2Troubleshooting Procedures
Satellite A660/A665 Series Maintenance Manual
45
perform the following procedures. Figure 2-17 outlines the process. Start with Procedure 1
and continue with the other procedures as instructed.
Procedure 1: Windows Application test
Procedure 2: Connector and replacement check
Procedure 1 Windows Application test
Run the functioning Program (record.exe) on Windows model, which will display the MIC
test result.
If tests and diagnostics result abnormal go to Procedure 2. If an error is not located, the MIC
module functioning is properly.
Procedure 2 Connector and replacement check
The MIC line or system board may be disconnected or damaged. Disassemble the computer
following the steps described in Chapter 4, Replacement Procedures, and perform the
following checks.
Check 1 Make sure that the MIC line is securely slotted into the system board. If the
problem remains, go to Check 2.
Check 2 The MIC line may be damaged. Replace it with a new one following the
instructions in Chapter 4. If the problem still exists, perform Check 3.
Check 3 The system board may be damaged. Replace it with a new one following the
instructions in Chapter 4.

Toshiba Satellite A660 Series Specifications

General

Optical Drive	DVD SuperMulti Drive
Wireless	Wi-Fi 802.11b/g/n
HDMI	Yes
Battery	6-cell Lithium-ion
Processor	Intel Core i5
RAM	4GB or 8GB DDR3
Storage	Up to 640GB HDD
Graphics	NVIDIA GeForce GT 330M
Operating System	Windows 7 Home Premium or Professional
Webcam	Yes, with built-in microphone
Audio	Stereo speakers, Dolby Advanced Audio
LAN	10/100 Ethernet
Card Reader	Multi-Card Reader
USB Ports	3 x USB 2.0
Ports	Microphone input, Headphone output
