OPERATOR’S MANUAL
series Robot Controller
Keys operative in this mode and their operations are shown below.
Key Descriptions
↑
Used to move the main cursor up. If the main cursor is
located on the top line of screen, the screen scrolls down.
↓
Used to move the main cursor down. If the main cursor is
located on the last line of screen, the screen scrolls up.
ALT + ↑
Used to move the main cursor up on the screen basis.
ALT + ↓
Used to move the main cursor down on the screen basis.
INS
Used to create a new coordinate data.
ALT +BS
Used to delete a coordinate data indicated by the main cursor.
All positional data contained this coordinate are also deleted.
EXE
The system proceeds to the detailed coordinate display where
you can edit a coordinate data indicated by the main cursor.
NEXT
Used to toggle the menu (resulting in the next menu).
ALT + NEXT
Used to toggle the menu (resulting in the previous menu).
STE 80720
– 5-50 –
