OPERATOR’S MANUAL
series Robot Controller
(c) Step 3: Mode selection.
Select [STEP] from the menu.
M O D E : T E A C H I N G / C O N T T E S T P R O
L :
O : 20%
M : F REE
S : S TOP
R E SET
M O D E : S T E P
C O N T C Y C L E S E G S T E P
(d) Step 4: Input through EXE key.
Make sure that your entry is correct, and press the EXE key. The step
operation mode is selected then.
M O D E : T E A C H I N G / S T E P T E S T P R O
O K L :
O : 20%
M : F REE
S : S TOP
R E SET
M O D E O V R D R E S E T D O W A T C H >
(e) Step 5: Execution of RUN.
Select [RUN] from the menu by means of the NEXT key, then press the EXE
key.
M O D E : T E A C H I N G / S T E P T E S T P R O
L :
O : 20%
M : F REE
S : S TOP
C O NT
M O V E A 1
STE 80720
– 6-11 –
