OPERATOR’S MANUAL
series Robot Controller
6.8.4 Output Signal Reset
(1) Function
Sets off all user external output signals (DOUT (1) ~ DOUT (164)). The hand
signals (201 ~ 204) will not turn off.
(2) Procedures
(a) Step 1: Command selection.
Press the NEXT key repeatedly until [RESET] is displayed in the menu, and
press the corresponding function key.
M O D E : T E A C H I N G / C O N T T E S T P R O
L : 28
O : 20%
M : F REE
S : S TOP
C O NT
M O D E O V R D R E S E T D O W A T C H >
Select [SIG].
M O D E : T E A C H I N G / C O N T T E S T P R O
L : 28
O : 20%
M : F REE
S : S TOP
C O NT
R E S E T : S I G
P R O G C Y C L E S T E P S I G S E L
STE 80720
– 6-28 –
