OPERATOR’S MANUAL
series Robot Controller
10.3 External Input/Output Signal Display [I/O]
(1) Function
Displays the status of external input/output signals.
(2) Procedures
(a) Step 1: File mode selection.
Press the NEXT key repeatedly until [I/O] is displayed in the menu. Press
the corresponding function key, and the following hand input/output signal
status display appears.
I / O M o n i t o r ( S t a n d a r d I N ) 1 / 5
1 10 11 20
D I N 0 * 0 0 000 00000 0000 0 0 0 000
2 * 0 0 000 00000 0000 0 0 0 000
4 * 0 0 000 00000 0000 0 0 0 000
6 * 0 0 0 0
D I N D O U T S Y S
For the display contents, see Step 2 below.
Keys operative in this mode and their operations are shown below.
Key Descriptions
←
Used to move the cursor to the left. When the cursor is
located on the left end, it will not move at all.
This key is effective when the [ON] menu or [OFF] menu is
displayed.
→
Used to move the cursor to the right. When the cursor is
located on the right end, it will not move at all.
This key is effective when the [ON] menu or [OFF] menu is
displayed.
↑
Used to move the cursor up. When the cursor is located at
the top, it will not move at all.
This key is effective when the [ON] menu or [OFF] menu is
displayed.
↓
Used to move the cursor down. When the cursor is located at
the bottom, it will not move at all.
This key is effective when the [ON] menu or [OFF] menu is
displayed.
