STE 80720
– 10-43 –
OPERATOR’S MANUAL
series Robot Controller
• Ext 1: Displays the axis-setting rotary SW.
• Ext 2: Displays the axis-setting rotary SW.
• Ext 3: Displays the axis-setting rotary SW.
• Ext 4: Displays the axis-setting rotary SW.
Keys operative in this mode and their operations are shown below.
Key Descriptions
ALT + ↓ or
NEXT or ↓
Used to display the next page. If the cursor is located at the
final page, the top page is selected.
ALT + ↑ or
ALT + NEXT or
↑
Used to display the previous page. If the cursor is located at
the top page, the final page is selected.
ESC
Used to return the system to the utility display.
Operations of each menu are shown below.
Menu Descriptions
[SYS] Displays the system version.
[ROBOT] Displays information on the robot.
[SEQ] Displays sequence information.
[AMP] Displays information on the servo amplifier.
To Next Page
