Toshiba TS3000 Series - 10.12 PLC Monitor [PLC-M]

STE 80720
– 10-45 –
OPERATOR’S MANUAL
series Robot Controller
10.12 PLC Monitor [PLC–M]
(1) Function
Displays the PLC data.
(2) Procedures
(a) Step 1: Command selection.
Press the NEXT key repeatedly until [PLC–M] is displayed in the menu.
Press the [PLC-M] key and the following PLC monitor display appears.
Press the contact menu you wish to display and the display item is changed.
The display contents on each page are as shown below.
• X display
P L C M o n i t o r ( X P L C - I n p u t ) 1 / 4
F - - - - - - 8 7 - - - - - - 0
X 0 0 * 00000000 00000 0 0 0
X 0 1 * 11000000 00000 0 0 0
X 0 2 * 00000000 00001 0 1 1
X 0 3 * 00000000 00000 0 0 0
X Y G H
• Y display
P L C M o n i t o r ( Y P L C - o u t p u t ) 1 / 4
F - - - - - - 8 7 - - - - - - 0
Y 1 0 * 00000000 00000 0 0 0
Y 1 1 * 00000000 00000 0 0 0
Y 1 2 * 00000000 00000 0 0 0
Y 1 3 * 00000000 00000 0 0 0
X Y G H
• G display
P L C M o n i t o r ( G P L C - > R O B O T ) 1 / 8
F - - - - - - 8 7 - - - - - - 0
G
0 0 * 00000000 00000 0 0 0
G
0 1 * 00000000 00000 0 0 0
G
0 2 * 00000000 00000 0 0 0
G
0 3 * 00000000 00000 0 0 0
X Y G H
