STE 80720
– 10-51 –
OPERATOR’S MANUAL
series Robot Controller
10.15 Ethernet Status Display [ETHER]
(1) Function
Displays the Ethernet status.
ETHER function is provided as standard in TS3000 and as an option in
TSL3000.
(2) Procedures
(a) Step 1: Command selection.
Press the NEXT key repeatedly until [ETHER] is displayed in the menu, and
then press [ETHER].
The screen shown below is displayed.
E T H E R N E T S T A T U S [ 1/3]
I P A D D R E S S 1 9 2 . 1 6 8 . 0 . 1 2 4
S U B N E T M A S K 2 5 5 . 2 5 5 . 2 5 5 . 0
M A C A D D R E S S 0 0 0 0 4 8 : 1 4 0 2 0 6
F I R M W A R E S 1 S 6 0 0 0 0 / 0 0 0 1 : 0 0 : 2 0
(b) Step 2: Display change.
The display items can be changed by pressing ALT key + ↓ key, the NEXT
key (or ALT key + ↑ key, ALT key + NEXT key).
The information displayed on each page is shown below.
[Page 1]
E T H E R N E T S T A T U S [ 1/3]
I P A D D R E S S 1 9 2 . 1 6 8 . 0 . 1 2 4
S U B N E T M A S K 2 5 5 . 2 5 5 . 2 5 5 . 0
M A C A D D R E S S 0 0 0 0 4 8 : 1 4 0 2 0 6
F I R M W A R E S 1 S 6 0 0 0 0 / 0 0 0 1 : 0 0 : 2 0
• IP ADDRESS: IP address of the robot controller itself that is written in the
"ETHERNET. PAR" [E01] file
• SUBNET MASK: Subnet mask of the network that is written in the
"ETHERNET. PAR" [E03] file
• MAC ADDRESS: MAC address of the robot controller itself
• FIRMWARE: Version of the Ethernet unit firmware
To Next Page
