STE 80720
– 10-50 –
OPERATOR’S MANUAL
series Robot Controller
Load factor display
L O A D 1 M i n 1 5 M i n 2 H o u r
J 1 : 5 0 . 2 % 4 5 . 1 % 4 2 . 5 %
J 2 : 3 2 . 1 % 2 8 . 7 % 3 3 . 2 %
J 3 : 2 4 . 5 % 3 4 . 8 % 2 9 . 8 %
J 4 : 2 . 5 % 1 2 . 0 % 1 2 . 1 %
J 5 : 0 . 0 % 0 . 0 % 0 . 0 %
T O R Q U T H E R M L O A D
• The current motor factor of each axis is displayed.
(100% = Rated load)
• The displayed values are the running averages for the duration of the
past one (1) minute, fifteen (15) minutes and two (2) hours.
• When the load factor under the column of "1 Min" or "15 Min" reaches
the specified value, the alarm saying "Axis* Motor overload", is
generated.
To Next Page
