STE 80720
– 10-60 –
OPERATOR’S MANUAL
series Robot Controller
Press the EXE key to start the backup.
R A M D I S K B A C K U P
P u s h E X E S A V E T h e n S T A R T
S A V E L O A D
During the backup process, "Saving" is displayed on the screen.
The backup process is complete when this message no longer appears.
R A M D I S K B A C K U P
S T A T U S : E M P T Y
B A C K U P D A T E : 0 4 / 0 3 / 1 5 1 6 : 2 5
S a v i n g
S A V E L O A D
The status when writing to the flash memory is shown below.
• STATUS Indicates the backup status.
EMPTY Empty
3 FILES 1024 BYTES
In the above example, 1024 bytes are used in three files.
• BACKUP DATE Indicates the date that the backup was made.
To Next Page
