8 Checklist
We recommend that you print out and work through the checklist for commissioning and when
replacing the measuring system of a previously accepted system and store it as part of the overall
system documentation.
Documentation reason Date Edited Checked
Sub-item To note Can be found under yes
Present user manual has
been read and understood
–
Document no.:
TR-ECE-BA-DGB-0070
Check that the measuring
system can be used for the
present automation task on
the basis of the specified
safety requirements
● Intended use
● Compliance with all technical
data
● Chapter
Intended use, Page 69
● Chapter
Technical Data, Page 102
Fulfillment of the installation
requirements defined in the
user manual
● Safe mechanical fixing of the
measuring system and safe
positive connection of the
driving shaft with the
measuring system
● Chapter
Assembly, Page 78
Requirement for the power
supply
● The power supply used must
meet the requirements of
SELV/PELV
(IEC 60364-4-41:2005)
● Chapter
Supply voltage, X1,
Page 88
Correct installation
● Observance of the EMC-,
cable- and shielding-
requirements
● Chapter
Installation / Preparation
for Commissioning,
Page 84
System test after
commissioning and change of
the counting direction
● During commissioning and
after each change of the
counting direction all affected
safety functions must be
checked
● Chapter
Safety functions of the
fail-safe processing unit,
page 71
● Chapter
Counting direction,
Device replacement
● It must be ensured that the
new device corresponds to
the replaced device
● All affected safety functions
must be checked
● Chapter
Counting direction,
Page 92
● Chapter Replacing the
Measuring System,
