5.3.2 Measuring systems, X2
PIN
Signal
Description
1
N.C.
do not connect!
2
Channel A –
RS422 / optional COSINE –, 1 Vss differential
3
Channel A +
RS422 / optional COSINE +, 1 Vss differential
4
N.C.
do not connect!
5
Channel B –
RS422 / optional SINUS –, 1 Vss differential
6
Channel B +
RS422 / optional SINUS +, 1 Vss differential
7
SSI_Data_m –
Data –, Master System, differential RS422
8
SSI_Data_m +
Data +, Master System, differential RS422
9
SSI_Clock_m –
Clock –, Master System, differential RS422
10
SSI_Clock_m +
Clock +, Master System, differential RS422
11
SSI_Data_s –
Data –, Safety system, differential RS422
12
SSI_Data_s +
Data +, Safety system, differential RS422
13
SSI_Clock_s –
Clock –, Safety system, differential RS422
14
SSI_Clock_s +
Clock +, Safety system, differential RS422
Cable specification: min. 0.25 mm
2
, stranded in pairs and shielded
