Troubleshooting and diagnosis options
 TR-Electronic GmbH 2004, All Rights Reserved Printed in the Federal Republic of Germany
Page 110 of 112 TR - ECE - BA - DGB - 0036 - 16 11/05/2018
8.2.2.7 Alarms supported
Extended diagnosis, bytes 18-19
Bit Significance = 0 = 1
bit 0
* Position error
not supported supported
bit 1
Supply voltage monitoring
not supported
supported
bit 2
Monitoring current load
not supported
supported
bit 3
Diagnosis routine
not supported
supported
bit 4
*
Memory error
not supported supported
bit 5-15
Not used
* is supported
8.2.2.8 Warnings
Extended diagnosis, bytes 20-21
Bit Significance = 0 = 1
bit 0
Frequency exceeded
no
yes
bit 1
Perm. temperature exceeded
no
yes
bit 2
Light control reserve
not achieved
achieved
bit 3
CPU watchdog status
OK
reset performed
bit 4
Operating time warning
no
yes
bit 5-15
Battery charge
OK
too low
8.2.2.9 Warnings supported
Extended diagnosis, bytes 22-23
Bit Significance = 0 = 1
bit 0
Frequency exceeded
not supported
supported
bit 1
Perm. temperature exceeded
not supported
supported
bit 2
Light control reserve
not supported
supported
bit 3
CPU watchdog status
not supported
supported
bit 4
Operating time warning
not supported
supported
bit 5-15
reserved
8.2.2.10 Profile version
The diagnosis bytes 24-25 show the version of the profile for PNO encoders
supported by the encoder. Decoding is performed on the basis of the revision number
and revision index (e.g. 1.40 corresponds to 0000 0001 0100 0000 or 0140 (hex) )
Extended diagnosis, bytes 24-25
byte 24 Revision number
byte 25
Revision index
