Parameterization and configuration
 TR-Electronic GmbH 2004, All Rights Reserved Printed in the Federal Republic of Germany
Page 90 of 112 TR - ECE - BA - DGB - 0036 - 16 11/05/2018
7.11 Description of the operating parameters
7.11.1 Count direction
Availability Page
PNO CLASS 1 16 Bit
PNO CLASS 1 32 Bit
81, 81
PNO CLASS 2 16 Bit
PNO CLASS 2 32 Bit
82, 83
TR-Mode Position
TR-Mode Position+Velocity
84, 85
TR-Mode High Resolution
TR-Mode High Resolution+Velocity
87, 88
The count direction defines whether ascending position values are output from the
measuring system if the measuring system shaft rotates clockwise or counter-
clockwise (view onto the measuring system flange connection).
7.11.2 Class 2 Functionality
Availability Page
PNO CLASS 2 16 Bit
PNO CLASS 2 32 Bit
82, 83
Defines the functional scope of the measuring system. Class 2 switched off means
only Class 1 functions are active in the measuring system; it does not scale the
position value and is not adjustable.
7.11.3 Commissioning diagnostics
Availability Page
PNO CLASS 2 16 Bit
PNO CLASS 2 32 Bit
82, 83
TR-Mode Position
TR-Mode Position+Velocity
84, 85
TR-Mode High Resolution
TR-Mode High Resolution+Velocity
87, 88
Defines whether the measuring system triggers a "diagnosis alarm" (OB82 for
SIMATIC

S7) for an internal error (memory or value jump > 1 revolution), also see
Chapter "Alarms", page 108.
