6 Operation with older GSD file revisions
GSD file: TR05AAAB.GSD
State: 09/14/2001
Device type: C_-65, C_-58
Firmware state: 4.x
Entry hardware catalogue: TR CE65M DP V4.0+
Comment: Base version
GSD file: TR09AAAB.GSD
State: 07/11/2005
Device type: 65, 58 – Encoder types
Firmware state: 4376AA_01 and 4376AB_01
Entry hardware catalogue: TR CE58_65M DP V1
Comment:
Expansion of the gear parameters in the TR-modes
„Position“ and „Position+Velocity“:
• Numerator lower limit: 1
• Numerator upper limit: 256.000
• Denominator lower limit: 1
• Denominator upper limit: 16.384
Limits:
•
If the number of revolutions is not an
exponent of 2 or is >4096, it can occur, if
more than 512 revolutions are made in the
de-
energized state, that the zero point of the
multi-turn measuring system is lost!
Compatibility to
TR05AAAB.GSD:
Limits:
• Numerator lower limit: 1
• Numerator upper limit: 62.464
• Denominator lower limit: 1
• Denominator upper limit: 99
