TR-Electronic CK-58 - Code PROFIBUS-Interface; Limit Switch Lower and Upper Limit; Velocity [1;X Rpm]

Parameterization and configuration
 TR-Electronic GmbH 2004, All Rights Reserved Printed in the Federal Republic of Germany
Page 98 of 112 TR - ECE - BA - DGB - 0036 - 16 11/05/2018
7.11.9 Code PROFIBUS-Interface
Availability Page
TR-Mode Position
TR-Mode Position+Velocity
84, 85
Defines the output code for the PROFIBUS interface.
7.11.10 Limit switch lower and upper limit
Availability Page
TR-Mode Position
TR-Mode Position+Velocity
84, 85
TR-Mode High Resolution
TR-Mode High Resolution+Velocity
87, 88
Is the status switched on (see Teach-In function page 91 and Status-byte page 99) the
measuring system can inform the master via a bit whether the actual value is within
the limits.
Limit switch bit = 0
Process-actual value ≥ lower limit switch or
Process-actual value ≤ upper limit switch
Limit switch bit = 1
Process-actual value < lower limit switch or
Process-actual value > upper limit switch
The inputs depend on the total measuring length in increments.
Lower limit
0
Upper limit
programmed total measuring length in increments – 1
Default Lower limit switch
0
Default Upper limit switch
4096
7.11.11 Velocity [1/x rpm]
Availability Page
TR-Mode Position+Velocity
85
TR-Mode High Resolution+Velocity
88
With this parameter, the specified rotational speed can be scaled in arbitrary steps
between 1/1 and 1/100 rpm. The rotational speed is output as two's complement
value. CW = positive, CCW = negative, with view onto the flange connection.
Default = 1 rpm.
