Trace Engineering PS Series User Manual

TECHNICAL INFORMATION
Page
122
Copyright  Trace Engineering Company, Inc.
5916 - 195th Street N.E.
Arlington, WA 98223
Telephone: 360/435-8826
Fax: 360/435-2229
www.traceengineering.com
PS Series Inverter/Charger
Part No. 3597
Rev. D: November 23, 1999
USER SETTINGS WORKSHEET
USER MENU (all models)
Your PS Series Inverter/Charger may have USER and/or SETUP operating settings that are different or
are changed from the standard factory settings. Use the following Record Sheets to record your specific
USER and SETUP operating settings for:
PS Series Inverter/Charger S/N .
MENU HEADING MENU ITEM
SELECTION
RANGE
DEFAULT
SETTINGS
USER
SETTINGS
Inverter Mode 1 Set Inverter OFF SRCH ON CHG OFF
Generator Mode 2 Set Generator OFF AUTO ON EQ OFF
Gen failed to start DISPLAY NO
Gen stopped due to V/F DISPLAY NO
Gen Max Run Time Error DISPLAY NO
Gen speed error DISPLAY NO
Load Amp Start Ready DISPLAY NO
Voltage Start Ready DISPLAY NO
Exercise Start Ready DISPLAY NO
Trace Engineering 3 Revision 5.0* PS AE DISPLAY
Meters 4 Inverter/charger amps AC DISPLAY 00
Input amps AC DISPLAY 00
Load amps AC DISPLAY 00
Battery actual volts DC DISPLAY Battery Volts
Battery TempComp volts DC DISPLAY Battery Volts
Inverter volts AC DISPLAY 00
Grid (AC1) volts AC DISPLAY 00
Generator (AC2) volts AC DISPLAY 00
Read Frequency Hertz DISPLAY 60
Read Bulk/EQ timer h:m DISPLAY 00:00
Error Causes 5 Low Battery voltage DISPLAY NO
Low inverter voltage DISPLAY NO
Low AC input voltage DISPLAY NO
High Battery voltage DISPLAY NO
High AC input voltage DISPLAY NO
Gen failed to start DISPLAY NO
Gen stopped due to V/F DISPLAY NO
Gen max run time error DISPLAY NO
Gen speed error DISPLAY NO
Over Current DISPLAY NO
Transformer overtemp DISPLAY NO
Heatsink overtemp DISPLAY NO
AC Source wired to output DISPLAY NO
External error (stacked) DISPLAY NO
Time of Day 6 SET HR/MIN/SEC 00:00:00
Generator Timer 7 Start Quiet time H:M 00:00 – 23:59 08:00
End Quiet time H:M 00:00 – 23:59 08:00
* Depending on your particular model, your software revision may be different.
