Trace Engineering PS Series User Manual

MENU SYSTEM
Page
44
Copyright  Trace Engineering Company, Inc.
5916 - 195th Street N.E.
Arlington, WA 98223
Telephone: 360/435-8826
Fax: 360/435-2229
www.traceengineering.com
PS Series Inverter/Charger
Part No. 3597
Rev. D: November 23, 1999
SETUP MENU
This section requires the use of the SWRC (or SWCA). The information in this section is based on using
the SWRC. In this section, whenever the SWRC is mentioned, the SWCA may be used instead.
The SETUP MENU provides all the controls and settings needed when installing or adjusting the system.
To access the SETUP MENU, press both the red ON/OFF MENU and green GEN MENU buttons on the
SWRC at the same time. To exit the SETUP MENU, press the red ON/OFF MENU button or press the
down MENU HEADING button until you reach the USER MENU (menu headings 1 – 8).
MENU HEADINGS
Inverter Setup
9
Use to program and adjust the operation of the inverter. Also allows
adjustment of how the inverter/ charger mode uses the utility grid.
Battery Charging
10
Use to adjust the operation of the battery charger.
AC Inputs
11
Use to adjust the operating characteristics of the utility grid (AC1) and the
generator (AC2) inputs, as determined by the
‘MAXIMUM AC AMPS IN’
switch.
Gen Auto Start
setup 12
Use to setup the when the automatic generator start system and the
maximum run time allowed
Gen starting
details 13
Use to adjust the starting sequence of the automatic generator start
system.
Auxiliary Relays
R9 R10 R11 14
Use to adjust the operation of the auxiliary signal relays for controlling
external power sources or system loads.
Bulk Charge
Trigger Timer 15
Use to set a time when the battery will be given a bulk charge cycle from
the utility grid input. Usually only used when SLT mode is enabled.
Low Battery
Transfer (LBX ) 16
Use to set up the transfer voltage setting for the LBX mode.
Battery Selling
17
Use to control the
SELL
mode when it is used to discharge a battery into
the utility grid. Also allows setting of the maximum sell amps.
Grid Usage Timer
18
Use to control when the inverter/charger mode uses the utility grid for the
FLT and SELL modes.
Information file
battery 19
Provides information about the operation of some settings and meters.
END SETUP MENU
20
Used to display that you have reached the end of the SETUP MENU.
