MENU HEADING - TIME OF DAY (6)
Provides the reference for any time functions enabled. Does not reset when the “PRESS FOR FACTORY
DEFAULTS” button is pressed. Will reset only if DC power is lost.
Set Clock hour
00:00:00
Indicates and allows setting of the hours for the internal clock. This setting is based on a 24-hour clock. It
adjusts in 10-minute increments.
Set Clock minute
00:00:00
Indicates and allows setting of the minutes for the internal clock. It adjusts in 1-minute increments.
Set Clock second
00
Indicates and allows setting of the seconds for the internal clock. It adjusts in 1-second increments.
MENU HEADING - GENERATOR TIMER (7)
These settings control the optional Generator Relay Module.
Start Quiet
time h:m 08:00
Generator will not be started during this period unless the actual battery voltage reaches the LOW
BATTERY CUT OUT VDC setting for a continuous period of 30 seconds. The quiet time period causes
the automatic generator start system to ignore the AC load and the 24 Hr, 2 Hr and 15 min battery voltage
start settings. The quiet time period is usually set for the sleeping hours.
End Quiet
time h:m 08:00
This setting finishes the quiet time period, allowing the generator to start as required by the settings of the
GEN AUTO START SETUP (12) menu heading in the SETUP MENU. To disable the quiet time, set the
start and end times equal.
If the generator exercise timer has reached the SET EXERCISE DAYS menu item setting, then the
generator will start at this time setting and will run for 15 minutes. If the SET EXERCISE DAYS menu item
is set for 01, then the generator will start every day at this time. To disable the generator exercise system,
set the number of days to zero.
INFORMATION DISPLAY
The following information is displayed as additional Menu Items.
Gen doesn’t run during quiet time unless batt volts is less than LBCO volts for 30 seconds.
or load > load start amps. To defeat timers set start = end.
If exercise days set to 1 then gen will always start @ end quiet
