Trace Engineering PS Series User Manual

TECHNICAL INFORMATION
Page
124
Copyright  Trace Engineering Company, Inc.
5916 - 195th Street N.E.
Arlington, WA 98223
Telephone: 360/435-8826
Fax: 360/435-2229
www.traceengineering.com
PS Series Inverter/Charger
Part No. 3597
Rev. D: November 23, 1999
SETUP MENU (PS2524)
To access the Setup Menu, press the RED and GREEN buttons on your SWRC at the same time. To exit
the Setup Menu, press the ON/OFF MENU button or use the down MENU HEADING button until you
reach the User Menu (menu headings 1 – 8).
MENU HEADING MENU ITEM SELECTION
RANGE
DEFAULT
SETTINGS
USER
SETTINGS
Inverter Setup 9 Set Grid Usage FLT SELL SLT LBX FLT
Set Low battery cut out VDC 16.0 – 35.5 22.0
Set LBCO delay minutes 00 – 255 15
Set Low battery cut in VDC 10.0 – 35.5 26.0
Set High battery cut out VDC 10.0 – 33.0 32.0
Set search watts 00 - 240 48
Set search spacing 00 – 255 59
Battery Charging 10 Set Bulk volts DC 20.0 – 32.0 28.8
Set Absorption time h:m 00:00 – 23:50 02:00
Set Float volts DC 20.0 – 32.0 26.8
Set Equalize volts DC 20.0 – 32.0 28.8
Set Equalize time h:m 00:00 – 23:50 02:00
Set Max Charge amps AC 01 - 25 20
Set Temp Comp LeadAcid Nicad LeadAcid
Read Bulk/EQ timer h:m DISPLAY 00:00
AC Inputs 11 Set Grid (AC1) amps AC 00 - 50 50
Set Gen (AC2) amps AC 00 - 50 30
Set Input lower limit VAC 80 - 111 108
Set Input upper limit VAC 128 - 149 132
Gen Auto Start Setup 12 Set Load Start amps AC 00 - 63 20
Set Load Start delay min 00.0 – 25.5 05.0
Set Load Stop delay min 00.0 – 25.5 05.0
Set 24 hr start volts DC 10.0 – 35.5 24.6
Set 2 hr start volts DC 10.0 – 35.5 23.6
Set 15 min start volts DC 10.0 – 35.5 22.6
Read LBCO 30 sec start VDC DISPLAY 22.0
Set Exercise period days 00 - 255 30
Set Maximum run time h:m 00:00 – 23:50 08:00
Gen Starting Details 13 Set RY7 Function GlowStop Run Run
Set Gen warmup seconds 16 - 255 20
Set Pre Crank seconds 00 - 255 10
Set Max Cranking seconds 00 - 15 10
Set Post Crank seconds 00 - 255 30
Auxiliary Relays R9 R10 R11 14 Set Relay 9 volts DC 10.0 – 35.5 29.0
R9 Hysteresis volts DC 00.1 – 12.8 02.0
Set Relay 10 volts DC 10.0 – 35.5 29.5
R10 Hysteresis volts DC 00.1 – 12.8 02.0
Bulk Charge Trigger Timer 15 Start Bulk Time H:M 00:00 – 23:50 00:00
Low Battery Transfer (LBX) 16 Set Low Battery transfer VDC 10.0 – 35.5 22.6
Set Low Battery cut in VDC 10.0 – 35.5 26.0
Battery Selling 17 Set Battery Sell volts DC 20.0 – 32.0 26.8
Set Max Sell amps AC 01 - 25 20
Grid Usage Timer 18 Set Start Charge time h:m 00:00 – 23:50 21:00
Set End Charge time h:m 00:00 – 23:50 21:00
