Load Amp Start
ready NO
If YES is displayed, it indicates that the automatic start system has started the generator or is about to
start the generator because the AC load current has reached the LOAD AMP START setting. The
automatic start is delayed by the time period set by the LOAD START DELAY MIN setting in the GEN
AUTO START SETUP (12). This allows checking of why the generator was automatically started.
Voltage Start
ready NO
If YES is displayed, it indicates that the automatic start system has started the generator or is about to
start the generator because the DC battery voltage reached one of the START VOLTS settings. The
automatic start is delayed by the time period of the START VOLTS setting involved in the GEN AUTO
START SETUP (12). This allows checking of why the generator was automatically started.
Exercise Start
ready NO
If YES is displayed, it indicates that the automatic start system has started the generator or is about to
start the generator because the EXERCISE PERIOD DAYS setting has been reached. This allows
checking of why the generator was automatically started.
INFORMATION DISPLAY
The following information is displayed as additional Menu Items.
Move cursor to GEN OFF to reset generator error. If no start in 5 trys then error.
If Gen runs for more than max run time then error. Under/Over speed will cause a Sync (Gen
stopped due to V/F) error in 10 minutes
MENU HEADING - TRACE ENGINEERING (3)
Press reset now
for defaults
Allows resetting of all menu item settings to the factory default values. This also occurs when the battery
is disconnected from the inverter. The RESET TO FACTORY DEFAULTS button on the SWRC will only
reset the default values if it is pressed while this menu item is displayed. All factory default settings will be
reset except for the TIME OF DAY (6) clock.
If the RESET TO FACTORY DEFAULTS button is pressed while in any other menu item or menu
heading, only the SWRC display is reset, no settings will be reset. This is useful for clearing any garbled
display information. This may be encountered when a remote display is initially connected or when a
remote is used in a high electrical noise environment such as a vehicle application.
Revision 5.0
PS AE
Displays the software revision. Used to ensure compatibility with other units when stacked, etc.
INFORMATION DISPLAY
The following information is displayed as additional Menu Items.
