Trane TR200 Series User Manual

6-02 Fire Mode Live Zero Timeout Function
Option: Function:
The function set in par.6-01
Live Zero Timeout Function will be activated
if the input signal on analog inputs is below 50% of the value defined in
parameter group 6-1* to 6-6* "Terminal xx Low Current” or “Terminal
xx Low Voltage" for a time period defined in par.6-00
Live Zero Timeout
Time.
[0] * Off
[1] Freeze output
[2] Stop
[3] Jogging
[4] Max. speed
6-1* Analog Input 1
Parameters for configuring the scaling and limits for analog input 1 (terminal 53).
6-10 Terminal 53 Low Voltage
Range: Function:
0.07 V* [0.00 - par. 6-11 V] Enter the low voltage value. This analog input scaling value should cor-
respond to the low reference/feedback value set in par.6-14
Terminal 53
Low Ref./Feedb. Value.
6-11 Terminal 53 High Voltage
Range: Function:
10.00 V* [par. 6-10 - 10.00 V] Enter the high voltage value. This analog input scaling value should cor-
respond to the high reference/feedback value set in par.6-15
Terminal 53
High Ref./Feedb. Value.
6-12 Terminal 53 Low Current
Range: Function:
4.00
mA*
[0.00 - par. 6-13 mA] Enter the low current value. This reference signal should correspond to
the low reference/feedback value, set in par.6-14
Terminal 53 Low Ref./
Feedb. Value. The value must be set at >2 mA in order to activate the Live
Zero Time-out Function in par.6-01
Live Zero Timeout Function.
6-13 Terminal 53 High Current
Range: Function:
20.00
mA*
[par. 6-12 - 20.00 mA] Enter the high current value corresponding to the high reference/feed-
back set in par.6-15
Terminal 53 High Ref./Feedb. Value.
6-14 Terminal 53 Low Ref./Feedb. Value
Range: Function:
0.000 N/
A*
[-999999.999 - 999999.999
N/A]
Enter the analog input scaling value that corresponds to the low voltage/
low current set in par.6-10
Terminal 53 Low Voltage and par.6-12 Termi-
nal 53 Low Current.
6-15 Terminal 53 High Ref./Feedb. Value
Range: Function:
50.000
N/A*
[-999999.999 - 999999.999
N/A]
Enter the analog input scaling value that corresponds to the high voltage/
high current value set in par.6-11
Terminal 53 High Voltage and par.
6-13
Terminal 53 High Current.
Parameter Description
116 TR200 Programming Guide

Trane TR200 Series Specifications

General

Input Voltage	24 VAC
Frequency Range	50/60 Hz
Communication Protocols	BACnet MS/TP, Modbus RTU
Controller Type	Programmable
Power Range	20 VA
Control Method	PID Control
Enclosure Rating	IP20
Operating Temperature	32°F to 122°F (0°C to 50°C)
Humidity Range	5% to 95% non-condensing
Memory	Non-volatile
