Trane TR200 Series User Manual

[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL Time-out 0
[31] SL Time-out 1
[32] SL Time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset Trip
[42] Auto Reset Trip
[43] OK Key
[44] Reset Key
[45] Left Key
[46] Right Key
[47] Up Key
[48] Down Key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
Parameter Description
TR200 Programming Guide 145

Trane TR200 Series Specifications

General

Input Voltage	24 VAC
Frequency Range	50/60 Hz
Communication Protocols	BACnet MS/TP, Modbus RTU
Controller Type	Programmable
Power Range	20 VA
Control Method	PID Control
Enclosure Rating	IP20
Operating Temperature	32°F to 122°F (0°C to 50°C)
Humidity Range	5% to 95% non-condensing
Memory	Non-volatile
