13-43 Logic Rule Operator 2
Array [6]
Option: Function:
Select the second logical operator to be used on the boolean input cal-
culated in par.13-40
Logic Rule Boolean 1, par.13-41 Logic Rule Operator
1, and par.13-42 Logic Rule Boolean 2, and the boolean input coming
from par.13-42
Logic Rule Boolean 2.
[13-44] signifies the boolean input of par.13-44
Logic Rule Boolean 3.
[13-40/13-42] signifies the boolean input calculated in par.13-40
Logic
Rule Boolean 1, par.13-41 Logic Rule Operator 1, and par.13-42 Logic
Rule Boolean 2. DISABLED [0] (factory setting). select this option to ig-
nore par.13-44
Logic Rule Boolean 3.
[0] * DISABLED
[1] AND
[2] OR
[3] AND NOT
[4] OR NOT
[5] NOT AND
[6] NOT OR
[7] NOT AND NOT
[8] NOT OR NOT
13-44 Logic Rule Boolean 3
Array [6]
Option: Function:
Select the third boolean (TRUE or FALSE) input for the selected logic rule.
See par.13-40
Logic Rule Boolean 1 for further descriptions of choices
and their functions.
[0] * False
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
Parameter Description
146 TR200 Programming Guide
