Page #143 background imageLoading...
Page #143 background image
13-4* Logic Rules
Combine up to three boolean inputs (TRUE / FALSE inputs) from timers, comparators, digital inputs, status bits
and events using the logical operators AND, OR, and NOT. Select boolean inputs for the calculation in par.
13-40
Logic Rule Boolean 1, par.13-42 Logic Rule Boolean 2 and par.13-44 Logic Rule Boolean 3. Define the
operators used to logically combine the selected inputs in par.13-41
Logic Rule Operator 1 and par.13-43 Logic
Rule Operator 2.
Priority of calculation
The results of par.13-40
Logic Rule Boolean 1, par.13-41 Logic Rule Operator 1 and par.13-42 Logic Rule Boolean
2 are calculated first. The outcome (TRUE / FALSE) of this calculation is combined with the settings of par.
13-43
Logic Rule Operator 2 and par.13-44 Logic Rule Boolean 3, yielding the final result (TRUE / FALSE) of the
logic rule.
13-40 Logic Rule Boolean 1
Array [6]
Option: Function:
[0] * False Enters the fixed value of FALSE in the logic rule.
[1] True Enters the fixed value TRUE in the logic rule.
[2] Running See parameter group 5-3* for further description.
[3] In range See parameter group 5-3* for further description.
[4] On reference See parameter group 5-3* for further description.
[5] Torque limit See parameter group 5-3* for further description.
[6] Current limit See parameter group 5-3* for further description.
[7] Out of current range See parameter group 5-3* for further description.
[8] Below I low See parameter group 5-3* for further description.
[9] Above I high See parameter group 5-3* for further description.
[10] Out of speed range
[11] Below speed low See parameter group 5-3* for further description.
[12] Above speed high See parameter group 5-3* for further description.
[13] Out of feedb. range See parameter group 5-3* for further description.
[14] Below feedb. low See parameter group 5-3* for further description.
[15] Above feedb. high See parameter group 5-3* for further description.
[16] Thermal warning See parameter group 5-3* for further description.
[17] Mains out of range See parameter group for further description.
[18] Reversing See parameter group 5-3* for further description.
[19] Warning See parameter group 5-3* for further description.
[20] Alarm (trip) See parameter group 5-3* for further description.
[21] Alarm (trip lock) See parameter group 5-3* for further description.
[22] Comparator 0 Use the result of comparator 0 in the logic rule.
[23] Comparator 1 Use the result of comparator 1 in the logic rule.
[24] Comparator 2 Use the result of comparator 2 in the logic rule.
Parameter Description
142 TR200 Programming Guide
