24-04 Fire Mode Max Reference
Range: Function:
50.000
FireMo-
deUnit*
[par. 24-03 - 999999.999
FireModeUnit]
Maximum value for the reference/set point (limiting the sum of value in
par.24-05
Fire Mode Preset Reference and value of signal on input se-
lected in par.24-06
Fire Mode Reference Source).
If running in Open loop when Fire Mode is active, the unit is chosen by
the setting of par.0-02
Motor Speed Unit. For closed loop, the unit is se-
lected in par.FB-02
Fire Mode Unit.
24-05 Fire Mode Preset Reference
Range: Function:
0.00 %* [-100.00 - 100.00 %] Enter the required preset reference/set point as a percentage of the Fire
Mode Max Reference set in par.24-04
Fire Mode Max Reference. The set
value will be added to the value represented by the signal on the analog
input selected in par.24-06
Fire Mode Reference Source.
24-06 Fire Mode Reference Source
Option: Function:
Select the external reference input to be used for the Fire Mode. This
signal will be added to the value set in par.24-06
Fire Mode Reference
Source.
[0] * No function
[1] Analog input 53
[2] Analog input 54
[7] Pulse input 29
[8] Pulse input 33
[20] Digital pot.meter
[21] Analog input X30/11
[22] Analog input X30/12
24-09 Fire Mode Alarm Handling
Option: Function:
[0] Trip+Reset, Critical Alarms If this mode is selected, the frequency converter will continue to run,
ignoring most alarms, EVEN IF DOING SO MAY RESULT IN DAMAGE OF
THE FREQUENCY CONVERTER. Critical alarms are alarms, which cannot
be suppressed but a restart attempt is possible (Infinity Automatic Reset).
[1] * Trip, Critical Alarms In case of a critical alarm, the frequency converter will trip and not auto-
restart (Manual Reset).
[2] Trip, All Alarms/Test It is possible to test the operation of Fire Mode, but all alarm states are
activated normally (Manual Reset).
Parameter Description
238 TR200 Programming Guide
