3-16 Reference 2 Source
Option: Function:
Select the reference input to be used for the second reference signal.
par.3-15
Reference 1 Source, par.3-16 Reference 2 Source and par.
3-17
Reference 3 Source define up to three different reference signals.
The sum of these reference signals defines the actual reference.
This parameter cannot be adjusted while the motor is running.
[0] No function
[1] Analog input 53
[2] Analog input 54
[7] Pulse input 29
[8] Pulse input 33
[20] * Digital pot.meter
[21] Analog input X30/11
[22] Analog input X30/12
[30] Ext. Closed Loop 1
[31] Ext. Closed Loop 2
[32] Ext. Closed Loop 3
3-17 Reference 3 Source
Option: Function:
Select the reference input to be used for the third reference signal. par.
3-15
Reference 1 Source, par.3-16 Reference 2 Source and par.3-17 Ref-
erence 3 Source define up to three different reference signals. The sum
of these reference signals defines the actual reference.
This parameter cannot be adjusted while the motor is running.
[0] * No function
[1] Analog input 53
[2] Analog input 54
[7] Pulse input 29
[8] Pulse input 33
[20] Digital pot.meter
[21] Analog input X30/11
[22] Analog input X30/12
[30] Ext. Closed Loop 1
[31] Ext. Closed Loop 2
[32] Ext. Closed Loop 3
3-19 Jog Speed [RPM]
Range: Function:
300.
RPM*
[0 - par. 4-13 RPM] Enter a value for the jog speed n
JOG
, which is a fixed output speed. The
frequency converter runs at this speed when the jog function is activated.
The maximum limit is defined in par. .
See also par.3-80
Jog Ramp Time.
3-4* Ramp 1
Configure the ramp parameter, ramping times, for each of the two ramps (par. 3-4* and par. 3-5*).
Parameter Description
76 TR200 Programming Guide
