Electrical Connections
43-06955 - Rev Q Page 47
Communications Interface
USB and RS-232 communications are supplied through interface connections
at the rear of the printer, as illustrated in the figure. The Serial RS-232
interface connector is a 9-pin DB connector and the USB interface is a
standard USB B connector.
Figure 12. Communication PCB Location and Connector Info.
Note: Pin-out configurations for these interfaces are documented in Chapter 2,
Epic 430
TM
Specifications and Requirements.
