Assembly and Disassembly
Page 68 43-06955 - Rev Q
Remote Mounting Applications
Figure 34. Base Plate and Paper Spindle for Remote Mounting Applications
For remote mounting applications, base plates are attached to the printer
mechanism (shown) and the base frame, using M3 Sems screws in
corresponding holes.
For applications where the Electronics Base Assembly is mounted
remotely, a separate Paper Spindle is attached to the Printer Mechanism,
using screws as shown.
