Assembly and Disassembly
43-06955 - Rev Q Page 63
Step 6. Add Top Cover Assembly
Figure 28. Top Cover Assembly Attached to Left Side Assembly
• Connect Top Cover Assembly to Left Side Assembly by positioning its
holes over corresponding studs, and then fastening three of these studs
(all but the upper right-hand corner, while looking at the outside of the Left
Side Assembly.
Attachment studs (2 of 3)
