Parts List
Page 72 43-06955 - Rev Q
No.
Description (standard parts)
Qty.
Part No. (History)
18
Guide - Top Paper
1
43-07006 (43-06404)
19
Harness - Cover Open Switch
1
43-06484L
20
Harness - Motors
1
43-05511L
21
Harness - Paper Out Sensor
1
43-06483L
22
Harness - Printhead
1
43-05509L
23
Harness - Sensors
1
43-05510L
24
Harness - TOF Sensor
1
43-05503L
25
Harness - Printhead (Folded)
1
43-06720
26
Assy - Knife Module (Full Cut)
1
43-10948 (43-09103, 43-07018, 43-07017,
43-06969, 43-06567)
27
Label - PCB Connector
1
43-06939
28
Latch Pin (Pivot)
1
43-06408
29
Latch Arm (Assy)
1
43-07004 (43-06424)
30
Motor Assy - Paper Feed
1
43-05505L (28-00759)
31
Nut - M3 Hex
8
98-0621
32
PCB - Interconnect
1
43-08918L (43-06464L)
33
Pin Pivot
1
43-06330
34
Pin - Slacker (Pivot)
1
43-06703
35
Platen
1
43-06970 (43-06435)
36
Retainer - 'E' Ring 0.25 Dia.
2
520-9800006
37
Ring - Retaining
7
520-9800002
38
Ring - Retaining
4
520-9800003
39
Screw - #4 Plastic Thread Forming
6
98-7608
40
Screw - M2x6
1
M068306-01 (98-7819)
41
Screw - M3x6mm PHPS PHD
4
98-0611
42
Screw - M3x6mm SEMS PHD PHPS
6
98-02215
43
Slacker (82.5mm Guide)
1
43-07409 (43-06702)
44
Spring - Compression (Printhead)
2
43-08710 (43-07005) (43-06429)
45
Spring - Torsion (Cover Open)
1
43-09451 (43-06426)
46
Spring - Torsion (Latch Arm)
1
43-06428 (43-06968)
47
Spring - Torsion (Slacker)
2
43-06971 (43-06704)
48
Stop Hinge (Cover)
1
43-06905
49
Stripper - Platen
1
43-06729 (43-06437)
