TDX Headend System Main Unit
Black Edition
23
EN
CAS server settings
 Enter relevant information – as example
shown here.
 Press the
UPDATE
button, down below.
Rebooting
1. Press the
Admin
button at the top of the right-
hand corner of the System window.
2. Expand the System maintenance area.
3. Press the
Reboot
button.
4. You will be prompted before reboot takes
place.
View
system log
It is possible to save log files for viewing headend
actions.
1. In the System maintenance – press
SAVE LOG
2. A txt file is saved to the Downloads folder in
Windows – see snippet above.
3. Open the TDXLOG.txt file in ie. Notepad or the
like.
4. Rename the file if needed
NOTE:
CAS system should be connected to the TDX system.
TDX should have quality input signal and user should
have a license.
NOTE:
Changes to IP addresses only take effect when the
headend has been rebooted.
