Triax TDX User Manual

TDX Headend System Main Unit
Black Edition
5
EN
Introduction
The TDX cabinet is designed to accommodate up to 16 input modules and 6 quad output modules. Up to three TDX headends can be combined as one
system of up to 48 input muxes and 72 output channels.
The TDX headend system accommodates up to 490 services.
All incoming signals from input modules initially arrive in the TDX service-pool, where conversion to defined output signals occurs, after which the
converted signals are fed to output modules.
Box contents
 TDX headend unit,
 1 x TDX Key 775310
 2 x Mounting brackets 775285
 4 screws (M4 x 8 hexagon ISO 7380)
840200)
 1 x Torx® key (2.5 mm) 848603
 1 x Power cord
 User guide.
Exterior
Input module area
Output module area
Mounting brackets
Lock
Headend status LEDs
Interior
