Triax TDX User Manual

TDX Headend System Main Unit
Black Edition
33
EN
Creating
The headend system offers the following possibilities
when you output IPTV services through the Link sockets.
 IP multicast streaming (UDP streaming)
 No RTP option
 IGMP version 2
 SPTS or MPTS including SDT, PAT, PMT, CAT
 Packet ratio of 1 TS packet per IP packet
 Not possible to change service ID (SID)
1. Select the
Output
tab.
2. Select the
IP outputs
sub-tab.
3. Press the
Setup
button for the link socket that
will process IP output.
4. Specify the desired
IP address
and associated
IP port number
in the corresponding fields.
5. Press the
Services
button.
The
Select Services
window displays services from input
that has entered the headend system through the same
unit which contains the Link socket(s) being used for
service distribution.
6. Select the services to be distributed through
the link.
7. Press the
UPDATE
button, down below.
Notes:
Services selected for one output on a Link will not be
selectable for other outputs on the same Link.
Re-scrambled and/or descrambled services cannot be
distributed using the Link sockets. They can, however, be
distributed using an IP output module and the AUX
sockets. The IP output module offers the possibility to
solve these limitations:
 RTP
 Set packet ratio for TS packets per IP packet
 Changing service ID (SID)
 Selection of descrambled service
 Selection of scrambled service
See the IP output module user guide for further
information.
Creating - continued
NOTE:
Licenses for IP output are required to be able to use
the IPTV functionality in the headend. The licenses
can be purchased from Triax Sales, and need to be
activated, see “Activating licenses”.
