5700/5800 GPS Receiver User Guide 179
NMEA-0183 Output A
5700 and 5800
The output of individual NMEA messages can be enabled or disabled
by:
• creating an application file in Configuration Toolbox that
contains NMEA output settings, and sending the file to the
receiver
• adding NMEA outputs in the Serial outputs tab of GPS
Configurator, and applying the settings
GSV Number of SVs in view, PRN, elevation,
azimuth, and SNR
185
HDT Heading from True North 185
PTNL,GGK Time, position, position type and DOP
values
186
PTNL,GGK_SYNC Time, synchronized position, position type
and DOP values
187
PTNL,PJK Local coordinate position output 189
PTNL,PJT Projection type 190
PTNL,VGK Time, locator vector, type and DOP values 190
PTNL,VHD Heading Information 191
ROT Rate of turn 192
VTG Actual track made good and speed over
ground
193
ZDA UTC day, month, and year, and local time
zone offset
194
Table A.1 NMEA message summary (continued)
Message Function Page
