TX9165 User Manual
TX9165-UM-EN-07 45
4.2.2.4 Log View
Details of the data present at the Trend
cursor position selected.
To Review the Trend
Use the navigation keypad, scroll up or down
to review the Log and select OK to view the
general Trend around the current Log entry.
Select OK to return to Log.
4.2.2.5 Exposure View
If a toxic Sentro eModule has been activated
to monitor STEL and TWA exposure limits,
an additional fifth view called Exposure View
will appear in the Sensor Inputs Overview.
Section 4.2.2.3
Section 4.2.2.3
www.trolex.com
