Model 3440 4–17
To take a standard count:
Ensure that the gauge base and reference standard block are
dry and free of debris.
Place the reference standard block on the standard count
site.
Ensure the source rod is in the SAFE position.
As shown in Figure 9, place the gauge on the reference
standard block, with the right side (keypad side) of the
gauge against the metal butt plate.
From the Ready screen, press ¢STD². The gauge displays
standard counts for density (DS) and moisture (MS):
Standard Count
DS= ####
MS= ####
Take New Count?
f To take a new standard count, press ¢YES² and follow
the instructions starting at step 6 below.
f To view the last four standard counts, press ¢NO² and
follow the instructions in the Viewing Standard Counts
section on page 4–21.
When taking a new standard count, the gauge displays:
Place Gauge on
Std. Block & Source
Rod in SAFE Pos.
Press <ENTER>
