Model 3440 8–7
O
O
u
u
t
t
p
p
u
u
t
t
P
P
r
r
o
o
j
j
e
e
c
c
t
t
The Output Project function within the Projects menu allows the
operator to print or upload project data stored in the gauge to a
computer or serial printer connected to the serial port, or to a
USB printer or flash drive connected to the USB port. To select
the output destination, see page 8–11.
NOTE
The USB port is included only on Model 3440 gauges.
Uploading or Printing Project Data
You can upload project data to a computer via the serial port
using Troxler’s Gauge Download Program, available at:
www.troxlerlabs.com/downloads/software/gaugedownload.zip
You can also upload the data using Windows
®
HyperTerminal or
TerraTerm. See the “Downloading Data” procedure at
www.troxlerlabs.com/documents for HyperTerminal instructions.
To output project data via the 9-pin serial port, connect a serial
cable to the port. An optional serial cable, P/N 113128, is
available from Troxler. Connect the serial cable to the
computer’s COM port (or a printer’s serial port).
To output project data to a USB printer via the USB port,
connect a USB cable to the USB port and connect the cable to the
USB printer. To output project data to a USB flash drive, connect
the flash drive directly to the USB port.
NOTE
The opening for the USB port will accept a device
with maximum dimensions of 10 mm (0.40 in.) high
by 29 mm (0.79 in.) wide.
A list of compatible USB devices is available at:
www.troxlerlabs.com/documents
