Model 3440 4–21
After the standard count passes, the operator can take
measurements with the gauge. When not taking readings,
always keep the source rod in the SAFE position. For added user
safety, the source rod automatically retracts to the SAFE
position when the gauge is lifted using the handle.
Viewing Standard Counts
To view the last four standard counts, press ¢NO² at the display
shown at the bottom of page 4–18. The gauge displays:
Standard Count
Want to View
Last Four Counts?
<YES> or <NO>
f Press ¢YES² to view the last four standard counts. The gauge
displays the last four density standard counts. Press ¢YES² to
view the last four moisture standard counts. Press
¢ENTER/START² to return to the Ready screen.
f Press ¢NO² to return to the Ready screen.
To Next Page
