TVS APACHE RTR 200 Fi 4V - Page 16

LOCATION OF PARTS - HANDLE BAR
1. Horn switch
2. Turn signal lamp switch
3. Clutch lever
4. Pass by switch
5. Rear view mirror L
6. High / low beam switch
7. Info switch
8. Connected instrument cluster
9. Ignition cum steering lock
10. Master cylinder (front)
11. Mode switch
12. Rear view mirror R
13. Engine cut off switch
14. Front brake lever
15. Throttle grip
16. Electric starter switch
17. Fuel tank cap
15
16
17
14
13
4
3
2
1
10
11
8
9
6
7
5
12
12
KNOW YOUR TVS APACHE RTR 200 Fi4V
