CHASSIS
Overall length : 2020 mm (without mud flap)
: 2050 mm (with mud flap)
Overall width : 790 mm
Overall height : 1050 mm
Seat height : 800 mm
Ground clearance : 180 mm
Wheel base : 1353 mm
Kerb weight (with toolkit : 152 kg
and 90% of fuel)
Pay load : 130 kg
Maximum laden weight : 282 kg
Steering angle : 35°
Caster angle : 25.8°
Frame : Double Cradle Split Synchro
STIFF (DCSSS)
Front suspension : Telescopic oil damped
Rear suspension : Gas charged Mono shock
absorber, 7 step adjustable
with rectangular swing arm
Trail length : 95.5 mm
TYRE*
Tyre size
Front : 90/90 - 17 49P Tubeless
Rear : 130/70 R17 M/C 62P Tubeless
(Radial tyre)
Tyre pressure
Front : 1.75 kg/cm² (25 PSI)
Rear - solo : 2.00 kg/cm² (28 PSI)
Rear - dual : 2.25 kg/cm² (32 PSI)
BRAKES
Front : Hand operated, 270 mm petal
disc
Rear : Foot operated, 240 mm petal
disc
TECHNICAL SPECIFICATION
* The pneumatic tyres fitted in this vehicle meet the
requirements specified by BIS and comply with the
requirements under the Central Motor Vehicles
Rules (CMVR), 1989.
91
