CLUTCH ADJUSTMENT
Clutch lever free play is one of the most important
adjustment which you may need to check in-between
services for better life of the clutch plates.
The free play of the clutch lever should be 8 ~ 13 mm
as measured at the clutch lever end at handle bar.
Adjust the clutch lever free play periodically by means
of clutch cable adjuster at arm clutch release. If the
free play is not within the specified limit.
1. Ensure that the engine is cold (engine oil at room
temperature).
7. The oil level should be between the minimum and
maximum level marks on the gauge as shown in
the figure.
8. If the oil level is below the minimum level, top up
with TVS TRU4 FULLY SYNTHETIC oil (SAE 10W 30
API-SL, JASO MA2) upto the maximum level mark.
Do not overfill.
9. Wipe out the oil traces with a clean cloth to
prevent dust accumulation and re-fix the gauge.
MAINTENANCE
Do not run the vehicle with insufficient / without
engine cum transmission oil as it will cause serious
damage to the engine components.
Excessive oil filling will cause oil leak and other
malfunctions. Always use TVS TRU4 FULLY
SYNTHETIC oil only (SAE 10W 30 API-SL, JASO
MA2).
Make sure that no foreign object gets in the crankcase
while topping up the engine oil.
Caution
Correctly recycle or dispose the used engine oil in
order to avoid environmental pollution.
Warning
73
